Industrial Control Host

(optional)

Windows:

• The industrial host control adopts a new generation of processors, high-speed chipsets, low power consumption, fast running speed, 3C certificated
• Working temperature -20~60 degrees;
• Win10 system, Intel-i3-4th generation CPU
• 8G memory, 128G solid state drive
• WiFi (4G is optional)
• Configuration can also be customized according to needs.

Android:

• Rockchip’s chip, low power consumption
• High performan 28nm HKMG pross, super quad-core Cortex-A17, RK3288 motherboard
• Memory 2GB 8GB flash 3*RS232 1*RS485 4*USB Ethernet WiFi Bluetooth
• Working temperature -20~60 degrees
• Android 7.1 system
• 4G full netcom module is optional

• Embedded industrial touch screen, sensitive, high temperature resistant, shockproof and explosion-proof
• Ten-point capacitive touch, durability: withstand more than 60,000,000 single-point touches, response speed: <2ms, positioning accuracy: more than 99% of the touch area is ± 3mm, minimum touch body: ≥1mm any current sensing object of the human body, scan rate: 60scans/s
• Touch resolution: 32767×32767, light transmittan: >91%, 3mm full tempered high-modulus 7-level explosion-proof glass

• 23.6 inch display screen: resolution: 1920×1080, display ratio: 16:9,
• Backlight type: LED liquid crystal display
• Viewing angle: 85/85/80/80, color depth: 16.7M, brightness: 250cd/m², response Time: ≤5ms.
• Port: 1×power, 1×VGA, 1×HDMI

Barcode and QR Code Scanner

(optional)

• Professional embedded two-dimensional scanning platform, professional book barcode scanner, can easily read one-dimensional barcode and two-dimensional code of mobile phones with various screen brightness.
• Built-in super-sensitive response module, fast sensing, fast barcode reading, soft light prossing;
• Light sour 5600K LEDs (illumination), Image sensor 752pixels(H)*480 pixels(V), Prossor ARM32-bit; Super large viewing angle up to 115 °*90°, ambient light resistance 100000Lux

Thermal Printer

(optional)

• Professional 80mm reipt thermal printer, supports electric door opening and paper change
• Printing density: 8 dots/mm.
• Printing direction: Paper feeding direction
• Printing speed: 150mm/s (Max)
• Paper width: 79.5±0.5mm.
• Effective printing width: 72mm.
• Paper handling method: automatic paper cutting.
• Line width: 3.75mm
• Serial communication
• With 3C and certification

• Power button, WiFi, 1 USB port, 1 network interface

• Input: 200-240V, output: 12V 12.5A, power 150W, 3C and certification;
• Working temperature range: -30℃ to +70℃;
• Can withstand 300VAC input surge voltage for 5s, output short circuit, overcurrent, overvoltage, Over temperature protection
